Formulating an IB Physics IA topic can be a challenging task for many learners. The investigation question must be practical and require analysis of key concepts to demonstrate the learner's subject matter understanding. This blog explores some of the IB Physics IA ideas to help learners choose a relevant research question.

IB Physics Internal Assessment Overview

The IB Physics Internal Assessment (IA) is a 3,000-word scientific investigation report submitted as part of the course. In this investigation, learners gather and analyse data for a self-formulated research question. The internal assessment component accounts for about 20% of the final IB grade. The IB evaluates the Physics internal assessment on the basis of four key criteria:

Research design, data analysis, conclusion, and evaluation. The total allotted marks for the IB Physics internal assessment are 24.

Understanding IA Requirements

IB Physics IAs must include a practical, relevant question with a feasible methodology and precise data collection methods. Examiners prioritise originality, personal engagement, and connections to core physics concepts. A good physics IA demonstrates critical analysis and clear conclusions. Graphical data presentation and the use of statistical tools can further enhance the presentation of the IB Physics Internal Assessment.

High-Scoring IB Physics IA Topics and Examples

Selecting good IB Physics IA ideas begins with choosing topics that are related to the syllabus. Below are some key IB Physics IA topic areas and some sample ideas.

Mechanics

• Examine how static friction opposes motion between common surfaces like wood and rubber.​
• Explore how the launch angle of an object affects a projectile’s range.
• Measure how the temperature of a ball or surface type affects its rebound height.

Waves and Oscillations Ideas

• Pendulum length versus oscillation period to calculate g (acceleration due to gravity).
• Study the effect of string material on resonance frequency.​
• Analyse the influence of medium density (air, liquid) on the speed of the sound wave.

Electricity and Magnetism

• Study how the number of coils in a solenoid affects the induced current​ due to magnet motion.
• Explore the influence of magnet strength on the electromotive force (EMF) induced in a coil.
• Examine the effect of temperature on a diode rectifier’s efficiency.

Thermal Physics

• Learn how the concentration of salt in water affects its specific heat capacity.
• Do a comparative thermal conductivity study of different metal rods.
• Determine the number of particles in a gas using the ideal gas law.

Optics

• Analyse the angle of incidence on reflection/refraction in prisms.​
• Study the behaviour of light through polarising filters.
• Investigate how the length of the fibre optic cable affects the intensity of the transmitted light.

IB Physics IA Examples and Methods

Examiners reward internal assessments with precise methods and insightful analysis. Here are some Physics IB IA examples along with method of experimentation.

Example 1: Pendulum Length and Oscillation Period

Research Question: How does pendulum length affect oscillation period?

In this IB Physics IA sample, construct a pendulum with adjustable lengths and measure the oscillation periods for each length. Record the oscillation period for at least five lengths. Maintain consistent mass for accurate data. Plot a graph for pendulum length versus oscillation period to analyse the results.

Example 2: Measuring Sound Through a Resonance Tube

Research Question: Can the speed of sound in a gas be determined using a resonance tube?

This research question will focus on measuring the speed of sound in different gases by using a resonance tube.

In this example, introduce the gas into a resonance tube. Arrange a speaker and microphone at fixed positions. Increase the speaker’s frequency gradually until resonance occurs and note the frequency. Then, to calculate the wavelength, measure the resonance length in the tube. Repeat with various gases to compare results. The investigation will measure the relationship between frequency, wavelength, and sound velocity.

Example 3: Density of Solid Materials

Research Question: How does the density of a solid vary with different types of materials?

For this research question, select different materials, including metals, plastics, and natural substances. Then, calculate the density using the mass and volume using precise tools. By using methods such as displacement and weighing, calculate the mass and volume. This helps analyse results and trends for the experiment.

Example 4: Refraction in a Prism

Research Question: How does the angle of incidence influence the angle of refraction in a prism?

This investigation examines the relationship between the angle of incidence and the angle of refraction through a prism. To carry out this IB Physis IA sample experiment, direct a light beam at a prism and vary the angle of incidence. Then measure the angle of refraction for each incidence angle. Repeat this method for several angles to plot the incidence versus refraction graph. Testing with Snell’s laws can help form a critical analysis of results.

Example 5: Radius and Torque Relationship

Research Question: What is the relationship between the radius of a wheel and the torque?

Explore the analysis of how the radius of a wheel influences the torque required to turn it. To conduct this experiment, set up an apparatus with wheels of varying radii. Then measure the torque required to turn each wheel using a dynamometer. The cycles can be repeated to check accuracy. For trend analysis, plot radius against torque.

More such IB Physics IA examples can help learners gain good scores in the exams.

Key Tips for Formulating IB Physics IA Ideas

• Choose topics of personal interest: Measuring the terminal velocity, oscillations, studying resonance, and experiments with the pendulum.
• Choose topics relevant to the syllabus: Prioritise topics that are a part of or relevant to the IB Physics syllabus. This can include topics such as mechanics, thermal, waves, and electricity.
• Choose easily measurable topics: Measures such as length, mass, angle, period, and frequency are easily measurable and feasible to conduct. It is also important to check for the availability of precision tools to verify experiments.
• Ensure practical scope: For best learning, choose topics that have real-world importance and implications.
• Modifying existing standard topics: Some experiments are classic, such as the simple pendulum or the inclined plane. Adding variations to these existing topics can help formulate new research questions.

Conclusion

Selecting engaging IB Physics IA topics is crucial to performance in the IB Physics Internal Assessment. This blog provides Physics IB IA examples along with ways to conduct the experiment to help learners in their journey. By prioritising the design, analysis, conclusion, and evaluation of the conducted experiment, learners can achieve high scores.

Check out the IB Diploma Programme at JAIN International Residential School. A school that provides strong support for the success of learners.

FAQs

Q1. What is the IA for IB Physics?

A1. The IB Physics Internal Assessment (IA) is a scientific investigation report with a maximum of 3000 words. The component carries nearly 20% of the final grade. The component emphasises research design, data analysis, conclusion, and evaluation.

Q2. How many pages should IB Physics IA be?

A2. IB Physics IAs are not page-limited, but have a maximum word count of 3000 words. This ensures concise and complete coverage of all the necessary sections.

Q3. What happens if you fail an IA in IB?

A3. Failing an IB Internal Assessment (IA) can significantly lower the overall score. This might even cause risk to university offers and the passing of the diploma. Hence, learners must retake the IA in the future IB session.
